Principal Particulars

LOA	12.00m
BOA	10.60m
Draught	2.80m
Displacement	4600kg

  Hull and Deck Structure ·         All structures designed in accordance with the ABS Guide for the Building and Classing of Offshore Racing Yachts ·         Cored hull and deck laminates using vinylester and epoxy resins, engineered fabrics and carbon fibre ·         Female moulded hull and deck ·         Integral moulded internal structure for keel and rig loads ·         Non slip surface on deck, coach house and cockpit ·         Moulded toe rails ·         Underdeck sliding hatch ·         Stainless chainplates ·          Quality iso-gelcoat exterior finish ·          Forward watertight crash bulkhead and aft watertight bulkhead   Mechanical and Steering ·         Yanmar 39hp with SD40 sail drive ·         2 Blade Folding Bri Ski Propeller ·         Wet exhaust, discharge through transom and water trap. Intake water through water strainer. Quality Diesel filter. ·         Morse control throttle at helm station ·         Engine instrument panel with tachometer and alarms mounted under companionway ·         Plastic 100ltr fuel tank. CE certified. ·         Custom tiller with optional wheel ·         Self-aligning rudder bearings, water tight for wheel steering. Accommodation ·         Interior Accommodation to meet IMS and IRC regulations ·         Sleeping accommodation for 6 including 1 double berth ·         Optional 2 pipe cots for racing ·         Optional cruising interior with additional aft cabin ·         Galley with SS basin, freshwater, built in insulated icebox and optional 12volt freezer ·         Folding removable Carbon centre table ·         Navigation table with seat ·         Enclosed head area with vanity, sink and head. ·         Optional hot water, shower, and electric sump drain ·         Sound insulated moulded engine cover incl. companionway steps ·         Hanging locker and storage opposite head forwards ·         100mm thick covered squabs ·         Exposed moulded areas finished in gloss gel coat with timber trim. Other areas finished with two pot semi gloss paint.   Deck Equipment ·         2 x 48ST Lewmar primary Winches ·         2 x 44ST Lewmar halyard Winches ·         2 x 44ST Lewmar main Winches ·         2 x 40ST Lewmar B/stay Winches ·         580mm low-profile round fwd hatch ·         Stainless steel fabricated pushpit and pulpit, stanchions and lifelines ·         Halyard blocks mounted on deck collar leading to Lewmar halyard clutches. ·         Under deck 2:1 Mainsheet, leading along boom to mast and to winches ·         RCB mainsheet traveller through ratchet block ·         Cunningham and outhaul on pod in cockpit with traveller control lines ·         6:1 traveller purchase all under deck ·         Adjustable Jib Cars with tackle ·         Spinnaker sheet with lock off foot block fwd, tweaker leads and brace block ·         2:1 Foreguy and 1:1 Tack line ·         Prod out control led to cockpit ·          40:1 Adjustable backstay   Spars and Rigging ·         Custom carbon spar with double swept spreaders ·         2:1 Main halyard ·         2 x Masthead Spi Sheaves ·         2 x Fractional Spi Sheaves and leads, 1 x Jib and Topping lift ·         Airfoil section alloy spreaders ·         Boom with two reef lines ·         Strut type boom vang ·         Twin groove head foil ·         Optional Spi Pole track with RCB Car and tackle adjustment ·         Windex and Light ·         Optional IRC carbon spi pole ·          Custom carbon retractable prod   Running Rigging ·         1 x Main Halyard ·         1 x Masthead Spi Halyard ·         2 x Fractional Spi Halyards ·         1 x Centre Halyard ·         1 x Topping Lift ·         1 x 2:1 Butt Lift ·         1 x Backstay Tackle ·         1 x Mainsheet ·         2 x Traveller ·         2 x Reefing Lines ·         1 x Vang Tackle ·         1 x Cunningham ·         1 x Outhaul ·         2 x Jib Sheets ·         2 x Jib Car Puller ·         2 x Inhauler ·         2 x Spi Sheets ·         2 x Tweakers ·         2 x Spi Braces ·         1 x Tack Line ·         1 x Pole Outline ·          1 x 2:1 Foreguy   Appendages ·         High lift fabricated steel fin with 2400kg lead bulb fitted into socket ·         All bolts 2205 hi-tensile stainless ·         Engineered carbon rudder stock ·          Balanced glass/foam rudder blade over carbon stock   Plumbing ·         Manual head and holding tank ·         Optional electric toilet ·         2 x 75ltr Bladder Water Tanks ·         Pressurised fresh water to galley and head. ·         Manual sea water pump to galley ·         Flush through hull fittings ·         2 x Manual bilge pumps ·         Optional roving electric bilge pump   Electrical ·         12volt DC main switch panel with circuit breakers, indicators, volt meter and charging indicator. ·         Separate engine start and 180 amp hour House Batteries. ·         LED Interior lights. ·         Tricolour navigation light, motoring and deck light on spar
